ASTM SAE 1018 Steel Bar

  • Introduction

SAE 1018 carbon steel is a free machining grade that is the most commonly available grade around the world. Although its mechanical properties are not very unique, it still can be easily formed, machined, welded and fabricated.


  • Chemical composition and Mechanical properties Of SAE 1018

Chemical composition(%) of  SAE 1018
ElementC%Si%MnSPFe
Content0.15-0.20≤0.050.60-0.90≤0.05≤0.045Balance



Mechanical properties of  SAE 1018

PerformanceTensile strength/MpaElongation /%Yield strength/Mpa
Proportion44015370

  • Application

It is widely used in

 Oil and Gas Pipeline

 Chemical Industry

 Plumbing
 Heating
 Oil & Gas Industry
 Water Supply Systems
 Paper & Pulp Industry
 Power Plant
 Fabrication Industry
 General purpose applications
 Food Processing Industry
 Structural Pipe
 Heat Exchangers

 Also used for other industrial purpose etc.


  • Other Analysis

Forging Properties:
Forging of SAE 1018 carbon steel can take place in the range of 996-1260°C (1825-2300°F).
Stress Relieving:
500°C – 700°C is required to relieve stress in AISI 1018 mild/low carbon steel that is later cooled down in still air.
Normalizing:
AISI 1018 mild/low carbon steel should be heated at 890°C – 940°C and then cooled in still air.
Annealing:
Complete annealing of this alloy can be achieved by soaking at 899°C (1650°F) followed by furnace cooling. Process annealing can be done at 649°C (1200°F)
