ASTM A106 Steel Pipe

  • Introduction

A106 pipe is American standard material, including A, B, C three grades, the ingredients of A106 A is carbon and silicon, the tensile strength grade is 330 MPa. The ingredients of A106 B is carbon,manganese and silicon, the tensile strength grade is 415 MPa. The ingredients of A106 C is carbon, manganese and silicon components, the tensile strength grade is 485 MPa.


  • Chemical composition and Mechanical properties Of ASTM A106


Chemical composition(%) of ASTM A106
ElementCSiMnSPCr
Content≤0.25≤0.10.27-0.39≤0.035≤0.035≤0.4


Mechanical properties of ASTM A106

PerformanceTensile strength/MPaElongation /%Yield strength/Mpa
Proportion(23°C)41516.5-30240


  • Application

It is usually used in industrial plants, power plants, refineries and chemical plants. In addition, for the reason of strength values conservation it is came into use in architectural projects. A106 grade pipe is a seamless pipe and there are three types: gr A, gr B and gr C. Among these, the most commonly used type is gr B.


  • Other Analysis

Tests:
1.Measurement of wall thickness changes

2.Tensile Test

3.Hardness Test

4.ASTM Grain Size Analysis


  • Benefits of ASTM A106

Pressure Tested

ASTM A106 is pressure tested to allow for liquids and gases to be passed through it.
Corrosion resistance
Carbon steel  can be resistant to corrosion due to the addition of lacquer coating, hot-dipped galvanizing, or zinc coating. This allows builders to use smaller, thinner pipes, even in environments that are acidic or extremely corrosive.
Shock Resistance
A106 steel  offers great resistance to vibration and shock.
High  Tensile Strength
ASTM A106 tested  has higher tensile strengths than welded one which make it safe to use in situations with very high pressures.

Cost-Effective

No matter the pressure that needs to be withstood, carbon A106 steel  can be much thinner than other types . This means that they have a greater carrying capacity than other pipes.

Why choose us:

*Top 20 companies in  steel industry trade volume.
 *Customized processing  steel one-stop purchase.
 *Exports of  steel exceeded tens of billions for 5 consecutive years.
 *We have a complete set of testing equipment, such as ut & ET, hydrauilc testinge quipment, spectrometer, scanning electron microscope, etc, and have   passed SGS TUV certification.
*JM Steel has hundreds of millions of high-end processing equipment at home and abroad, including precision cutting equipment: advanced Italian Nova stainless steel Kaiping production line, Taiwan Weitai stainless steel cross-cutting line, Taiwan Weitai stainless steel slitting line, large-scale stainless steel cold and hot rolling Flattening machine, slitting machine, etc.

For More details of each item,contact our sales to know more about it.Thanks for your visiting of JMJDWX Steel,save our web.You will be more professional in steel industry.
